Bridge Abutment Construction 1.7m Wide Platform Jump Formwork System

Product Description

Dam And Bridge Abutment Construction Jumping Formwork System

Description

The characteristics of high bridge piers are the height of the pier, the high center of gravity, the small cross-sectional area relative to the height of the pier, the flexibility of the pier, the high requirements for construction accuracy, the difficult axis control, and the high requirements for construction joint treatment.

The climbing formwork construction method not only saves construction materials, the construction speed is fast, but also the concrete surface is smooth and beautiful. It is currently the most advantageous construction method in the construction of high piers.

Elements
• Title back formwork unit could be timber beam large size formwork or steel formwork

• Triangle brackets bearing concrete pressure

• Panel travelling unit is option if reinforcement installation space is required

• Anchoring system 20.0 with high loadability

Features
•Main platform is 1.70 m wide for safe operation

• Formwork is title back or 600mm retraction space is also possible

• 3 levels of platform provide space for concrete pouring, formwork operation and concrete surface repairing

• Max. permitted pull force is 200kN per bracket for embedded tie rod

Climbing Formwork Installation Process

Packing

Applications Field
