Timber Beam H20 formwork for slab

Minimum Order Quantity : 400sqm Packaging Details : Pallet
Delivery Time : 25-30 Work days Payment Terms : L/C, T/T, D/A
Supply Ability : 100000 M2 / Year
Place of Origin: Shanghai Brand Name: ForPro
Certification: ISO and CE Model Number: Timber beam table formwork

Detail Information

Color: Customized Application: Concrete Construction, Slab Pouring, Building Exterior Wall, Construction And Reinforced Concrete Wall, Slab Formwork
Product Name: Shuttering Formwork For Construction, Aluminum Formwork System Concrete Forming System Concrete Formwork, Aluminium Formwork System Manufacturer In China, Steel Concrete Column Formwork Components: Aluminium Parts And Steel Accessories, Beam/Pillar/Wall/Prop/Floor/Reinforcement System, Wall, Stairs, Column
Feature: Efficient, Easy Operation, High Safety Performance

Product Description



Timber Beam H20 Slab Formwork System for efficient and Easy operation





Outline



All made from Q345B (S335 DIN EN10025:), the galvanized or powder coated, or both on all the component. By the combination of panels, aux beams and bridge beam (or panel), the system deals with complex slab structure by very simple way. Formwork for Beam, filler for Column and Wall side will be not difficult anymore. Alternative way is to use the standard panel sitting on the lower level support mechanism as the beam bottom. the formwork is pre-assemled in factory and  transported directly to jobsite for application. Jobsite assembly in advance is another better option for long distance transportation. The whole table system can be fast repositioning thanks to combination of transportation fork or trollery and crane lift. As a modular table formwork, no individual parts need  to be carried from one place to new position, It Means not only labour costs will saved, but also work effeciency will be greated promoted.



Erection procedure

Timber Beam H20 formwork for slab 0

Timber Beam H20 formwork for slab 1

Timber Beam H20 formwork for slab 2




Applications

Timber Beam H20 formwork for slab 3
