Beams Columns And Slabs Formwork Systems T Form 350mm Thickness

Product Description

Formwork For Beams Columns And Slabs Formwork Systems T Form With High Efficiency

Outline
T-Form is a cost-effective slab formwork system , with only 3 basic components and ready to use panel makes formwork construction become much simply and high efficiency. early strip head is specially equipped at the same time to decrease total material quantity and save formwork costs.

All components are made from Q345B (S335 DIN EN10025:), the galvanized or powder coated, or both on all the component. By the combination of panels, aux beams and bridge beam (or panel), the system deals with complex slab structure by very simple way. Formwork for Beam, filler for Column and Wall side will be not difficult anymore. Alternative way is to use the standard panel sitting on the lower level support mechanism as the beam bottom.

Main components

• Slab panel

          Steel frame and 12mm plywood is riveted into steel frame.

• Steel prop with early strip head
• Intermediate beam

Technical data

• Light panel formwork for widely range of applications, small size panels can be handy mounted
• Panel widths is up to 1.20m and width is up to 1.80m
• Maximum permissible slab width for max. panel size (1.20mx1.80m): 350mm;
• Shift wheel device is available for moving formwork unit to new position.

T-Form Panel dimension

Erection procedure

Application field

• Residential House
• Factory
• Civil engineering projects
