Adjustable Circular Column Formwork For Different Architecture

Minimum Order Quantity : 1000sqm Price : depends on material price
Packaging Details : Pallet Delivery Time : 15-20 work days
Payment Terms : L/C, T/T Supply Ability : 1000000 Sqm / year
Place of Origin: shanghai Brand Name: ForPro
Certification: ISO and CE Model Number: Timber Beam H20

Detail Information

Features: Simple And Efficient And Easy To Operate Material: Q235 Steel, Timber Beam,Plywood
Color: Colorful With Yellow,Blue,Black Size: Universal Forming And Customized
High Light:

Adjustable Circular Column Formwork

,

Architecture Circular Column Formwork

,

Q235 Steel Column Formwork System

Product Description

Adjustable circular Column Formwork for different architecture



Outline
No matter geometry, size and height, Timber beam column formwork can form any columns. With standard timber beam H20 and steel waler, the column formwork could be quickly assembled with less labour costs. With customized big size plywood, It is easy to achieve first class concrete surface. After assembling, the whole column formwork could be lift as one unit to new position. One time assembly and several reuse cycling, Timber beam column formwrok provide not only better concrete surface but also speedy construction time.The system has the same parts with wall formwork.



Detail

1. Material: Concrete column formwork is made of H20 timber beam, the panel thickness can be 18mm
2. Components: Steel concrete column formwork system include flat formwork, coner formwork, internal corner formwork, external corner formwork, formwork clamps.
3. Max. permissable pressure is 80kN/m2
4. Max.Cross section is 1.0mx1.0m without in-through tie rod
5. Flexible adjustment to fit different column dimension



Adjustable Circular Column Formwork For Different Architecture 0
