Wall And Slab Aluminium Formwork System With High Concrete Pouring Rate

Product Description

Aluminium Concrete Formwork for Wall and Slab More Reuses and High Efficient

Outline

For monolithic construction method ,ForPro Aluminium formwork is one ideal formwork option, Formworks of walls, columns, slabs and beams as well as stairways are installed simultaneously. Aluminium formwork is a cost-effective solution for forming social residential buildings featuring frequently repetitive floor plans. The aluminum elements are prefabricated on a project-specific basis and can be assembled without the use of a crane, Comparing to traditional manual wooden formwork, ForPro Aluminium formwork can increase the jobsite efficiency by 1/3.

Main components

1. Aluminiu panel system

Wall panel, Beam panel, Deck panel, KC, Stair, etc;
Width:100mm/200mm/300mm/400mm/600mm

2. Tie rod system

Flat Tie, Steel waler, Vertical waler, Tie rod, etc;

3. Supporting and shoring system
Balancing, Raking shore, MB, EB, Horizontal rod, Adjustable prop, Props; etc.;

4. Auxiliary system
KB, K screw, L screw, The drip line, Round Pin & Wedge pin, Box, Working Stool, etc

Product Advantages
Easy to handle

Aluminium formwork is manufactured with aluminum alloy and every extrusion is specifically designed for high strength and light weight. Even for the biggest panel, it can be easily handled by a single worker.

One -time Pouring

Aluminium formwor allows for monolithic pouring of all walls, slabs and staircases to suit any housing projects.

High Concrete Pouring Rate

With one-floor forms and three-floor props, the workers will be able to complete the concrete pouring job of one floor within 4 days.
More Reuses time
Typical number of reuses is likely to be≥300 times subject to the correct site practice.
Great Recyclable Value
The used aluminum material is of great recyclable value, over 35% higher than steel.

Applications

Forpro Service

Provide support in every stage of projects
1.Provide cosult when client take part in projects bid invitation.
2.Provide optimized formwork tender solution to assitant client to win the project.

3.Developing formwork design, refining initial plan, and exploring relation limit between supply&demand.

4.Start to design the formwork detailedly according to the winning bidding.
5.Provide economic formwork solution package and provide continous on-site support service.
