Super High Rise Building Concrete Slab Formwork Systems T Form With High Efficiency

Product Details:
Place of Origin: Shanghai
Brand Name: ForPro
Certification: ISO and CE
Model Number: Customized
Payment & Shipping Terms:
Minimum Order Quantity: 100 sqm
Price: $100-150 / M2
Packaging Details: Pallet
Delivery Time: 25-30 Work days
Payment Terms: L/C, T/T
Supply Ability: 100000 M2 / Year
  • Detail Information
  • Product Description

Detail Information

Material: Q235 Steel Color: Blue, Gray, White Powder, Silver Coated
Application: Concrete Construction, Slab Pouring, Building Exterior Wall, Construction And Reinforced Concrete Wall, Slab Formwork Product Name: Plastic Formwork For Construction, Aluminum Formwork System Concrete Forming System Concrete Formwork, Aluminum Formwork System Manufacturer In China, Steel Concrete Column Formwork
Components: Aluminium Parts And Steel Accessories, Beam/Pillar/Wall/Prop/Floor/Reinforcement System, Wall, Stairs, Column Feature: Efficient, Easy Operation, High Safety Performance
Type: Wall Form Concrete Wall Formwork System,Slab Formwork System Name: Concrete Slab Formwork System,Concorete Formwork,shoring Prop
High Light:

concrete slab systems

,

table formwork for slab

Product Description

Table Slab Formwork System T-Form for Super High-Rise Building



Outline
T-Form is a cost-effective slab formwork system , with only 3 basic components and ready to use panel makes formwork construction become much simply and high efficiency. early strip head is specially equipped at the same time to decrease total material quantity and save formwork costs.



Main components

  • Slab panel

          Steel frame and 12mm plywood is riveted into steel frame.

  • Steel prop with early strip head
  • Intermediate beam



Technical data

  • Light panel formwork for widely range of applications, small size panels can be handy mounted
  • Panel widths is up to 1.20m and width is up to 1.80m
  • Maximum permissible slab width for max. panel size (1.20mx1.80m): 350mm;
  • Shift wheel device is available for moving formwork unit to new position.



T-Form Panel dimension



Slab panel Panel size weight
Description WxH (mm) (kg)
TF0606 600x600 13.5
TF0906 900x600 18
TF0909 900x900 22
TF1206 1200x600 22
TF1209 1200x900 26
TF1212 1200x1200 32
TF1506 1500x600 25
TF1509 1500x900 33
TF1512 1500x1200 40.6
TF1806 1800x600 30
TF1809 1800x900 38
TF1812 1800x1200 45



Erection procedure

Super High Rise Building Concrete Slab Formwork Systems T Form With High Efficiency 0



Application field

  • Residential House
  • Factory
  • Civil engineering projects

Super High Rise Building Concrete Slab Formwork Systems T Form With High Efficiency 1
