Tableform H20 Concrete Slab Formwork Systems For Floor Slab Construction
Contact Person : Liu
Phone Number : 86-18011399169
WhatsApp : +8618280345525
Detail Information |
|||
Material: | Q235 Steel | Color: | Customized |
---|---|---|---|
Application: | Concrete Construction, Slab Pouring, Building Exterior Wall, Construction And Reinforced Concrete Wall, Slab Formwork | Type: | Wall Form Concrete Wall Formwork System,Slab Formwork System |
Thickness: | 12mm Panel | Weight: | Average 3KG/SQM |
High Light: | House Slab Formwork Systems,House Slab Formwork Systems T Form,Steel Prop Slab Formwork Systems |
Product Description
Outline
Main components
Steel frame and 12mm plywood is riveted into steel frame.
Technical data
T-Form Panel dimension
Slab panel | Panel size | weight |
Description | WxH (mm) | (kg) |
TF0606 | 600x600 | 13.5 |
TF0906 | 900x600 | 18 |
TF0909 | 900x900 | 22 |
TF1206 | 1200x600 | 22 |
TF1209 | 1200x900 | 26 |
TF1212 | 1200x1200 | 32 |
TF1506 | 1500x600 | 25 |
TF1509 | 1500x900 | 33 |
TF1512 | 1500x1200 | 40.6 |
TF1806 | 1800x600 | 30 |
TF1809 | 1800x900 | 38 |
TF1812 | 1800x1200 | 45 |
Application field
