Steel Plywood Wall Formwork System For Hydropower Stations

Product Description

Wall Shuttering Formwork System For Large Area Can be Customized

Product Description

Wall Shuttering Formwork Systemare used in large-volume concrete projects, such as hydropower stations, energy sources, bridges, stations, and super high-rise buildings. This formwork system is widely used all over the world and has very strong versatility. It solves the problems of poor quality of traditional formwork concrete, low turnover and poor safety factor!

Technical Specification

1.Plywood thickness is 18mm , Max dimension is 2mx6m (Customized size).

2.Timber beam height is 200mm, width is 80mm, length is from1m to 6m. Permitted bending moment is 5KN·m;permitted shear force is 11kN;

3.Steel waler is a welded double U profile 100 or 120, slot holes are drilled on the waler flange for universal application.

Applications

Bridge

LNG

Hige-rise building

hydropower stations
